Ptac Wall Sleeve Installation Instructions

Page 3 pre installation considerations before proceeding with the sleeve installation ensure the following guidelines for locating the wall opening and sleeve are met.

Ptac wall sleeve installation instructions.

For sunrooms and modular buildings adhere to their installation instructions for supporting and sealing sleeve to their frames. Consult a licensed contractor as needed. Wall case should be sealed caulked to the inside wall on all four 4 sides. Standard steel wall cases are 42 w 16 h 13 3 4 d.

While the dimensions may appear to be incompatible the 2 devices should fit properly. The air conditioner will slide into the sleeve but is not flush with the wall. Figure 4 minimum interior and exterior note. Inches mm inches mm inches mm wall sleeve only 3 75 0 0 0 0 subbase kit 3 75 3 1 4 85 2 3 4 70.

To ensure proper airflow and filter removal it is recom mended installation of the wall sleeve be a minimum of 36 from the ceiling. In applications where the drain holes on the ptac wall sleeve are not exposed beyond the wall an internal drain system is recommended. Prepare and install the new wall sleeve according to the instructions below. Tools required by.

In applications where the drain holes on the ptac wall sleeve are not exposed beyond the wall an internal drain system is recommended. All wall and window wall installations must provide for proper drainage. Installation guidelines for sealing ptac sleeves read these instructions completely before starting any installation. This information might be about you your preferences or your device and is mostly used to make the site work as you expect it to.

Wall case must be sealed caulked to outside wall on all four 4 sides. 16 24 28 and 31 deep cases are available for thicker walls. For new installs ensure the wall is properly framed to support the weight and dimensions of the wall sleeve and air conditioner. The wall sleeve must be fastened securely before installing the air conditioner unit.

When you visit any website it may store or retrieve information on your browser mostly in the form of cookies. For sunrooms and modular buildings adhere to their installation instructions for supporting and sealing sleeve to their frames. If the sleeve projects more than 8 into the room a sub base or other means of support must be used. See the drain kit for internal actual installation instructions.

The sleeve will fit flush in the wall extending outside the structure. Insure that the unit is only installed in a wall structurally adequate to support the unit including the sleeve chassis and accessories. There is a portion of the air conditioner which extends a few inches back into the room. All wall and window wall installations must provide for proper drainage.

Failure to install and maintain our product according to these instructions may void any product warranty.
